| Model number : T35(Integrated) | |
| Rated lifting weight: 3500kg | Engine model: Yunnei/Quanchai 495 |
| Rated lifting height: 3000-6000mm | Drive mode: four-wheel drive |
| Load center distance: 600mm | Axle : 280 High and low speed torque converter |
| Minimum turning radius: 2500mm | Tire type : Cast steel wheel steering axle |
| Maximum climbing Angle: <38° | Wheelbase:1697mm |
| Minimum ground clearance: 320mm | Frame steel width: 160mm(plus heavy duty) |
| Front/back Angle of frame :10.0/8.0 | Fork length: 1220mm(optional) |
| Maximum operating speed :35km/h | Weight: 5500kg |
| Maximum hook traction: 30.0KN | Machine size: 3200/1500/2300mm |
