HS-20 2ton electric forklift

Immediate consultation

Product Details:

Our 2 ton electric forklift is a cost-effective, eco-friendly material handling solution designed for daily indoor and light outdoor logistics operations. As one of the most popular electric warehouse forklifts on the market, it combines stable 2000kg load capacity, zero-emission operation and low energy consumption, perfectly replacing traditional diesel forklifts for modern green warehouses. Equipped with advanced lithium battery technology and intelligent ac control system, this 2 ton battery powered forklift delivers long working hours, low failure rate and smooth running performance, helping enterprises cut operational costs and improve handling efficiency significantly.

Product Profile:

Item Specification
Characteristics
Model HS-20
Driving mode seated
Rated capacity 2000 kg
Load center distance 500 mm
Power mode lead-acid battery
Wheelbase 1550 mm
Performance
Travel speed, laden/unladen 9 / 10 km/h
Lifting speed, laden/unladen 180 / 200 mm/s
Lowering speed, laden/unladen 550 mm/s
Maximum negotiable gradient, laden/unladen 15 / 20 %
Weight
Service mass (with battery) 2480 kg
Axle load: unloaded, front/rear —
Axle load: loaded, front/rear —
Battery voltage / nominal capacity 72V / 156Ah
Battery weight 180 kg
Electrical configuration
Drive motor power-60 minutes 4 kW
Lift motor power-15 minutes 4 kW
Drive motor controlling mode MOSFET/AC
Lifting motor controlling mode MOSFET/AC
Service brake / parking brake Hydraulic / Mechanical
Tyre
Tyre type Solid tire (original typo: Solid fetus)
Wheels number (front/rear) 2 / 2
Front track W3: 945 mm
Rear track W2: 880 mm
Tyre (front) 18*7-10
Tyre (rear) 16*6-8
Size
Front overhang L2: 320 mm
Tilt of the mast, front/rear α/β: 5 / 10 °
Height, mast retracted H1: 2030 mm
Free lift height /
Overall maximum lift height H: 3000 mm
Height, mast extended H2: 4055 mm
Overhead guard height H4: 2110 mm
Lateral Fork Adjustment (Outside of Forks) Max/Min 1040 / 100 mm
Fork size (L×W×T) 401001070 mm
Truck body length (fork excluded) L’: 2230 mm
Truck body width W1: 1096 mm
Turning radius R: 2280 mm
Ground clearance under mast H5: 88 mm
Ground clearance at center of wheelbase(laden) H6: 110 mm
Width of aisle right-angle stacking (pallet1000×1000mm clearance 200mm) Ast: 3850 mm
Width of aisle right-angle stacking (pallet1200×1200mm clearance 200mm) Ast: 3950 mm
